Pressure Sensor and Switch

Slider Image
Slider Thumb

This Pressure Gauge is engineered for accurate pressure readings across various industrial systems. It provides stable performance even in demanding environments. The gauge features a clear dial for easy visibility and a rugged design to withstand mechanical stress. It is suitable for air, water, oil, and compatible gases used in industrial processes. The stainless steel body ensures long term reliability and resistance to corrosion.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Fluid medium Air
  • Indicated pressure range (gauge) 0～0.8MPa
  • Tolerance ±5% (Full scale)
  • Operating temp. range 0～60℃（No freezing）
  • Scale angle 150°
  • Model Pg-100
  • Dial Size One Hundred Millimetre
Other Attributes
  • Pressure Range Zero To Ten Bar
  • Connection Size One By Four Inch
  • Display Type Analog
  • Material Stainless Steel
  • Accuracy One Point Six Percent
  • Mounting Type Bottom Mount
Slider Image
Slider Thumb

The digital pressure gauge is designed for accurate and real time pressure monitoring in industrial environments. It features a clear digital display for fast readings and ensures consistent performance. The compact construction allows easy installation and reliable operation even in demanding conditions. The device provides stable readings and supports a wide range of pressure measurement requirements across industries.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Fluid medium Air, non-corrosive/non-flammable gas
  • Battery CR2032 Lithium battery (*2)
  • Battery life About 3 years (at 5 times indication/day)
  • Rated pressure range Negative pressure:-101～0kPa/Positive pressure:0.000～1.000MPa
  • Indicated pressure range Negative pressure:-101～10kPa/Positive pressure:-0.100～1.000MPa
  • Proof pressure Negative pressure:300kPa/Positive pressure:1.5MPa
  • Ambient temp. range Operation:0～50℃, Storage:-10～60℃ (No dew condensation, no freezing)
Other Attributes
  • Ambient humidity range Operation/Storage:35～85%RH (No dew condensation)
  • Display Type Lcd Display
  • Pressure Range Zero To One Thousand Bar
  • Accuracy Level High Precision
  • Power Source Battery Operated
  • Body Material Stainless Steel
  • Connection Type Threaded Port
Slider Image
Slider Thumb

The handy manometer is designed for precise and consistent pressure measurement in both industrial and laboratory environments. It features a compact body enabling easy portability for field operations. The device uses high quality internal sensing elements to provide stable readings across varying operating conditions. Its digital display ensures clear visibility of pressure values even in low light environments. The rugged construction offers long term durability and dependable performance for continuous usage.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Rated pressure range Compound gauge pressure (low range) type:-101～100kPa/Compound gauge pressure type:-100～1,000kPa/Absolute pressure type:0～100kPa abs
  • Max. pressure Compound gauge pressure (low range) type:200kPa/Compound gauge pressure type:1,500kPa/Absolute pressure type：200kPa abs
  • Indication system 3 & 1/2 digits LCD
  • Operating temp. 0～50℃ (No freezing)
  • Operating humidity 15～85％ RH or below (No condensing)
  • Driving power 3VDC, 2 x AAA dry cell (*2)
  • Pressure port M5x0.8 female thread
Other Attributes
  • Protection structure IP40 (IEC standard) (*3)
  • Model HM-100
  • Display Type Digital Lcd
  • Measurement Range Zero To One Thousand Mbar
  • Accuracy Plus Or Minus Zero Point Five Percent
  • Battery Type Lithium Ion
  • Material Abs Plastic
Slider Image
Slider Thumb

The mechanical pressure sensor is engineered to provide dependable performance in both low and high pressure environments. It features a rugged stainless steel body that ensures durability in demanding industrial conditions. The sensor utilizes a mechanical sensing mechanism to deliver stable readings without the need for electrical power. Its analog dial display enables easy on site monitoring and quick pressure verification. This device is suitable for continuous operation and supports a wide range of industrial systems.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Pressure detection Diaphragm to Micro switch
  • Fluid medium Air
  • Operating pressure range 0～-100kPa
  • Operating temp. range 0～60℃ (No freezing)
  • Electrical rating 3A 250V
  • Pressure setting range -20～-66kPa
  • Model Mps-100
Other Attributes
  • Pressure Range Zero To One Hundred Bar
  • Accuracy Plus Or Minus One Percent
  • Material Stainless Steel Body
  • Connection Type Threaded Process Port
  • Operating Temperature Minus Ten To Seventy Degree Celsius
  • Output Type Mechanical Dial Indication
  • Protection Class Ip65 Rated
Slider Image
Slider Thumb

This digital pressure sensor is engineered for accurate pressure monitoring in compact installation spaces. The eight millimetre width and LED display provide clear visibility in various lighting conditions. The device offers high precision readings and stable output performance, making it suitable for automation and process control systems. The durable construction ensures long term reliability in demanding industrial settings.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Fluid medium Air,non-corrosive/non-flammable gas
  • Pressure detection Diffused metaloxide semiconductive pressure transducer
  • Operating pressure range Negative pressure type:-100～100kPa/Compound pressure type:-100～300kPa
  • Proof pressure Negative pressure type:400kPa/Compound pressure type:0.6MPa
  • Operating temp. range 0～50℃ (No freezing)
  • Storage temp. range -20～70℃ (Atmospheric pressure, Humidity 65% RH or less) (No freezing)
Other Attributes
  • Operating humidity range 35～85% RH (No dew condensation)
  • Protective structure IEC standard IP40 equiv.
  • Power supply 12~24VDC ±10%, Ripple (P-P) 10% or less
  • Current consumption 30mA or less (All LED and no-load of 2 switch outputs: ON)
  • Sensor Width Eight Millimetre
  • Display Type Led Display
Slider Image
Slider Thumb

The LED digital pressure sensor is designed to provide accurate and stable pressure monitoring for various pneumatic and automation systems. It features a bright LED display that ensures clear visibility even in low light environments. The compact structure allows easy installation in limited spaces and supports both analog and digital output for flexible integration with controllers. It is built with durable engineering materials offering long service life and consistent performance under different operating conditions.

Cash,Cheque,NEFT and RTGS

Key Attributes
Industry-specific Attributes
  • Sensor Type Led Digital Pressure Sensor
  • Display Type High Visibility Led Display
  • Pressure Range Wide Pressure Measurement Range
  • Output Type Analog And Digital Output Options
  • Accuracy High Accuracy Detection
Other Attributes
  • Response Time Fast Real Time Response
  • Operating Voltage Stable Low Voltage Operation
  • Body Material Durable Engineering Plastic
  • Mounting Method Panel And Inline Mounting
  • Application Suitability Pneumatic And Automation Systems
